| λ-Amp 広帯域半導体光増幅器 / Wide-Band Solid State Optical Amplifier |
|||
|---|---|---|---|
| # | λ-Amp 950 | λ-Amp 1040 | λ-Amp 1100 |
| Wavelength Tuning Range |
920nm-1000nm (30dB Gain) |
980nm-1085nm (30dB Gain) |
1030nm-1120nm (20dB Gain) |
| Max. Output Power |
> 1W (without Isolator) > 700 mW (with Isolator) |
> 100 mW | |
| PM-Fiber Coupling |
80% (any wavelength, without Dispersion Compensation) 70% (whole wavelength, with Dispersion Compensation) |
||
| Max. Current | 2,000 mA (Full Size Case with TEC) 1,500 mA (Compact Case) |
400 mA | |
| Spectral Purity | 0.1 ~ 0.0005 | --- | |
Related Data
Output Power
Output Spectra
